CK-Series Interactive Board

Name: China CK-Series Interactive Board Manufacturers, Suppliers and Factory - Custom Service - HDFocus Tech
Brand: HDFocus
SKU: 241918819

◆ Excellent slim design with aluminum alloy edging, matte grey and black color;
◆ Ultra high 4K resolution and new original panel with TFT LED backlight;
◆ Sensitive 20 points IR touch;
◆ Built in professional Anti-Glare glass;

Send Inquiry

Specification

Description

Technical Parameters

Product Outlook

1 2

Products Description

This CK interactive whiteboard has various functions and supports wireless projection without complicated wiring. You can easily share content on the whiteboard whether it is a mobile phone or a computer. Moreover, this whiteboard can also support remote collaboration, which is very suitable for enterprises to conduct remote video conferencing and improve meeting efficiency.

Main Features

Wireless screen projection

Our digital whiteboard does not require complicated cable connections. You can easily share content on the whiteboard screen with just a mobile phone or computer. It is very convenient and can improve meeting or teaching efficiency.

Brand new original TFT LED backlight panel

The TFT LED backlight panel we use can provide excellent color reproduction and contrast, making the colors bright and full, and the images clear and sharp. Whether it is text, pictures or videos, they can be presented in the most realistic and vivid state, bringing users the ultimate visual experience. And our panels have undergone strict quality inspection and screening, and can withstand long-term use and frequent operation, and are not prone to failure and damage.

Magnetic stylus can be adsorbed on the front frame of the board

Our magnetic stylus can be adsorbed on the front frame of the interactive whiteboard. This stylus has a strong adsorption capacity and can be firmly fixed on the front frame of the whiteboard. This function ensures that the stylus always has a fixed place to be placed and will not be lost or rolled away at will. This feature is particularly important for those scenarios where interactive whiteboards need to be moved and used frequently. Because it greatly reduces the inconvenience caused by the loss of the stylus, and also avoids the additional costs incurred.

Built-in annotation function

Whether it is Android system or Windows system, users can easily use the built-in annotation function. And users can quickly download the annotation content on the whiteboard to their mobile phones by scanning the QR code, which is convenient for viewing and sharing anytime, anywhere. For students, important notes in class can be saved to their mobile phones for easy review after class; for business people, key comments in meetings can be shared with team members in time to improve work efficiency.

Display

Display Screen	55 Inch	65 Inch	75 Inch	85 Inch	86 Inch	98 Inch	110 Inch
Panel back light	TFT-LCD Module with DLED backlight
Panel Protection	Tempered Glass Anti-Glare glass (OPTIONAL)
Aspect Ratio	16:09
Color	1.07B colors (10 bit)
Display area	1209.6*680.4mm	1429*804mm	1650*928mm	1872*1053 mm	1895.04*1065.96 mm	2158.85*1214.35 mm	2436.48 *1370.52mm
Resolution	3840*2160						3840*2160
Brightness	350cd/m2					450cd/m2
Contrast	4000:1
Response Time	5ms
View Angle	178° left and right, up and down
Life	Over 60,000 hours

IR Touch

IR Touch		Capacitive Touch
Touch Type	Infra-red	Touch Type	Capacitive touch
Points	20 points	Points	10 points (can customize 40 points)
Response Time	Less than 5ms	Response Time	Less than 6ms
Resolution	32767 * 32767	Resolution	32767 * 32767
Position Accuracy	±1mm	Position Accuracy	±1mm
Communication	USB2.0	Communication	USB2.0
Touch Way	Pen, Finger or other light-proof items	Touch Way	Pen, Finger or other light-proof items
Life Time	Over 60,000,000 touches	Life Time	Over 80,000,000 touches

Dual OS Configuration

Android Configuration		Windows OPS Configuration (OPTIONAL)
CPU	Quad-core ARM Cortex-A55	Sky Lake-S 6th Gen processors	I3-6320/I5-6400/I7-6700
GPU	Mali-G52 MP2(2EE)	DDR4/RAM	4G/8G/16G/32G/64G (Optional)
RAM	8GB DDR4	Hard disk/SSD	SSD 128G/256G /512G/1TB (HDD 1TB Optional)
ROM	64G/128G EMMC	Graphics card	Intel® HD Graphics card 530 integrated
WIFI	IEEE802.11an 2.4/5 GHz	WIFI & BT	IEEE802.11an 2.4GHz+5G, BT4.2
Hotspot	IEEE802.11 a/b/g/n Dual Band 2.4GHz/5 GHz	Windows OS	Windows 8.1/10/11 trial version, Linux
Bluetooth	Support, can receive signal up to 12M.
Android OS	Android 11.0 and above

Input/output Interface

Android I/O Interface

Front Port	USB*3
	HDMI IN*1
	TOUCH*1
	TYPE-C*1
Rear Input Port	USB*3
	Type C*1
	HDMI IN*2
	RS232*1
	RJ45 IN*1
	VGA IN*1
	PC Audio IN*1
	DP IN*1
	TF card slot*1
Rear Output Port	HDMI OUT*1
	RJ45 OUT*1
	Touch OUT*1
	Earphone*1
	Optical OUT*1
Bluetooth/WIFI	1x2.4G built-in module,1x 5G built-in module
Bluetooth/WIFI	Bluetooth5.0*1

Windows OPS I/O Interface, based on 6th Generation OPS (Only available with OPS built in,for customized OPS, the I/O interfaces are different)

DP Output	DP*1
HDMI Output	HDMI*1
MIC IN	MIC*1
RJ45 Port	RJ45*1
USB Port	USB 2.02,USB 3.04
Type-C	Type-C*1
LINE-OUT	LINE-OUT*1
Power	Power*1
Restore	Restore*1

Accessories

Remote Controller	Remote controller*1
Wall Mount Racker	Racker*1
Touch Pen	Free Touch Pen*2
User Manual	User Manual*1
Power cable	Power cable*1

Others

Net Dimension	1258.2757.684.8mm	1483.288491.8mm	1705.41008.991.8mm	1951.61148.691.8mm	1951.61148.691.8mm	2158.851313.596.33mm	2502.041498.6669.5mm
Package Dimension	1370880180mm	16001000200mm	18001130200mm	20601270200mm	20601270200mm	23401423260mm	26802701655mm
Net Weight	27KG	40KG	56KG	71KG	72KG	125KG	100KG
Gross Weight	32KG	48KG	66KG	83KG	83KG	135KG	130KG
Speaker	2*12W speakers (Front)
VESA	400*400mm	400*500mm	400*600mm	400*800mm	400*800mm	400*1000mm	1000*800mm
Color	Top and bottom in Silver, left and right in Black
Voltage	100 V ~ 240 V, 50-60 Hz
Power	≤ 280W			≤ 380W
Working Temperature	0－ 40 ℃

Detailed Dimension Drawing

Front and Side

Back

White Board Software

Main Features

●Our CK series interactive whiteboard software supports Android system and wireless sharing;

●Our software supports gesture recognition function. Among them, three-finger touch can bring up the floating menu to follow, and five-finger touch can bring up the power on/off screen. In addition, pen recognition and erasing functions can be realized by changing the touch area, and it supports writing and erasing at the same time.

●Our whiteboard software supports wireless screen projection from mobile phones, and the software can be reversely controlled through mobile phones;

●Our software has a built-in eraser function and supports gesture erasing;

●Our whiteboard software has an annotation function, which can be annotated on Android and Windows systems, and the annotation content supports QR code scanning to download to the mobile phone or save locally on the interactive whiteboard;

●Our whiteboard software supports QR code sharing, and the content can be downloaded directly through QR code scanning;

●Our interactive whiteboard software can record audio and pictures in MP4 format;

●Our whiteboard software supports wireless screen projection, whether it is a mobile phone or a PC, it can be projected;

●Our interactive whiteboard supports the smart U disk lock function, and the whole machine touch and key lock can be set on the software;

●Our software supports intelligent recognition of handwritten text and conversion to standard English fonts, and supports opening a new window to search for handwritten text through a web browser;

●Our interactive whiteboard supports half-screen mode, pull the upper part of the Windows display down to the lower part of the display, and you can still operate the Windows system normally by touch.

EShare Wireless Transmitter (OPTIONAL)

Model: HDT1

●Our EShare wireless transmitter supports wireless projection, which can project PC signals onto the interactive whiteboard. At the same time, reverse control can also be performed, making the user more convenient and efficient during operation.

●Our EShare wireless transmitter has ultra-low power consumption, which means that the wireless transmitter can run stably for a long time without frequent charging or battery replacement, bringing users a more convenient use experience.

●Our Eshare wireless transmitter adopts classic plastic shell and LED lighting design; the classic plastic shell makes the wireless transmitter lighter, easier to carry and install, while the LED lighting design can provide clear instructions and status display during use, so that users can understand the working status and connection status of the wireless transmitter.

●Our EShare wireless transmitter is plug-and-play, and no software needs to be installed. This means that when using it, users only need to plug the wireless transmitter into the corresponding device and start using it immediately.

●Our EShare wireless transmitter supports 2.4G and 5.8G dual-band, which is more stable and fast during transmission.

●Our Eshare wireless transmitter transmits audio and video up to 1080P resolution and 30FPS.

Detailed Specification
Interface	USB2.0(5V/500mA)
Supported OS	Windows 7 and above, macOS 10.10 and above
PC Minimum Spec	Frequency: 1.8GHz and above; RAM: 2G and above
InputResolution	Input resolution support up to 3840*2160
Project Resolution	1080P@25~30fps
Audio Transfer	44.1KHz/16bit, stereo audio
Wireless Project	Plug and play, auto run, no need to install any software
Wireless Protocol	IEEE 802.11ac /802.11n
Wireless Band	2.4G&5.8G
Wireless Distance	Maximum 35M
Transmission Delay	Less than 50ms
Reverse Touch Control	Reverse touch control, maximum support 10 points touch
Extended Screen Transfer	Windows 10 PC can wireless transfer extend screen

EShare Wireless Solution Control Software

Control Software Main Features
File Push Function	Support push picture, video, audio and Office file to locallydisplay
Fileupload function	Upload any fileswirelessly totheinteractive whiteboard,users can download this file and displayin the screen
Intelligent control	Intelligent control function: Wireless Touch Mouse, air mouse, Wireless keyboard Voice Handwriting input, Wireless Touchpad, Remote control for common keys (Home Menu BackVol+/-..etc.)
Wireless camera	Support wireless camera
Annotation	Mobile phone and Windows PC can do wireless annotation tothe interactive whiteboard screen.
TV Mirror	The interactive whiteboard screen can be shared to a mobile device wirelessly, and this mobile device can reverse touch control interactive whiteboard screen simultaneously
SplitScreen Display	Can wireless project 9 mobile devices signals to the interactive whiteboard screen with 9 split screens display
Moderator Control	The moderator can control the permissionsofthe client devices, such as screen transfer, reverse screentransfer, touch, annotation and exclusive screen display
Airplay	Compatiblewith AirPlay protocol, any iOSdevices can use AirPlay functionto wirelessproject screen without install any APP
DLNA Protocol	Compatible with DLNA protocol,any App which support DLNA protocol can wireless project screen to the interactivewhiteboard screen
iOS Project	iOS devices can wireless project screen to interactive whiteboard screen,and can reverse touch control the iOS devices through theinteractive whiteboard screen
Android Project	Android OS devices can wireless project screen to interactive whiteboard screen, andcan reverse touch control the Android OS devices through the interactive whiteboard screen
Extended Screen Project	Wireless Dongle terminal can do extended screen wirelesstransfer for the Windows 10 devices
Screen Group Display	Support the simultaneous transmission of one single signal to multiple interactive whiteboard screens for synchronous display with the wireless receiver product

VC Module(OPTIONAL)

VC module is used with video conference software, such as zoom.

Camera1	48M pixels
Camera2	48M pixels motion and audio tracking camera(optional)
Number of Arrays	8 microphone sound arrays system
Noise Cancellation	Support noise cancellation
Voice Pickup range	Up to 10M
